Kensington SD5800T Thunderbolt 4 and USB4 Quad Video Docking Station - for Notebook, Tablet PC, Monitor - Charging Capability - Memory Card Reader - SD, microSD - 170 W - Thunderbolt 4 - 4 Displays Supported - 4K, 2K, 8K, 6K, Full HD, QHD - 3840 x 2160, 7680 x 4320, 2048 x 1080, 1920 x 1080, 2560 x
K32856NA
Also known as DHK32856NACA,IMB32300,SY7362711
MARKETING INFORMATION
Unlock the full potential of your premium laptop.
Ideal for professionals and creatives who want more screens for visual productivity, more speed to work with large files, support for multiple 4K monitors, and more ports so they can connect to accessories without using adapters, the SD5800T Thunderbolt™ 4 and USB4® Quad Video Docking Station is a highspeed dock that provides everything you need to unlock the full potential of your premium laptop.
As one of the first Thunderbolt™ 4 docks capable of supporting Quad 4K displays, the SD5800T Thunderbolt™ 4 and USB4® Quad Video Docking Station provides a powerful plug-and-play connection- including support for four 4K monitors for the latest Windows laptops and two 6K monitors for the latest MacBook models, 40Gbps data transfer speeds, up to 100W charging (98W certified), and a 16-in-1 design.
The SD5800T Thunderbolt™ 4 and USB4® Quad Video Docking Station delivers more screens, more speed, and more power-so you can be more productive and focused.
Features include:
- Plug-and-play solution for Thunderbolt™ 4, Thunderbolt™ 3, USB4®, and USB-C®
- Windows (10 or later) or macOS (11 or later)
- 40Gbps of data, video, and audio
- Up to Quad 4K video for Windows and up to Dual 6K for MacBook
- Up to 100W Charging (98W certified)
- 16 Productivity Ports
- Supports Zero-Footprint Mounting
- Kensington Security Cable Lock Slots
- 3-year limited warranty and Kensington DockWorks™ Software
DETAILS
- Connectivity Technology : Wired
- Charging Capability : Yes
- Number of Displays Supported : 4
- Supported Resolutions : 2048 x 1080,3840 x 2160,7680 x 4320,1920 x 1080,2560 x 1440
- Screen Mode Supported : Full HD,6K,2K,QHD,8K,4K
- Memory Card Reader : Yes
- Memory Card Supported : microSD,SD
- Device Supported : Monitor,Notebook,Tablet PC
- Ethernet Technology : 2.5 Gigabit Ethernet
- Host Interface : Thunderbolt 4
- Total Number of USB Ports : 7
- Number of USB 2.0 Ports : 1
- Number of USB 3.2 Gen 1 Type-A Ports : 2
- Number of USB 3.2 Gen 2 Type-A Ports : 3
- Number of USB Type-C Ports : 1
- USB Type-C : Yes
- USB Type-C Detail : 1 USB-C 3.2 Gen2 de 10 Gbps
- Number of USB Type-A Ports : 6
- USB Type-A : Yes
- Number of RJ-45 Ports : 1
- Network (RJ-45) : Yes
- Number of DisplayPorts : 2
- DisplayPort : Yes
- DisplayPort Version : 1.4
- Headphone/Microphone Combo Port : Yes
- Number of HDMI Ports : 2
- HDMI : Yes
- HDMI Version : 2.1
- Thunderbolt : Yes
- Thunderbolt Ports Quantity : 1
- Number of Thunderbolt 4 Ports : 1
- USB Power Delivery : 100W
- Operating System Supported : macOS Big Sur,Windows 10
- Maximum Power Supply Wattage : 170 W
- Product Color : Black,Cool Gray
- Height : 7.68" (195 mm)
- Width : 4.09" (104 mm)
- Depth : 1.42" (36 mm)
- Weight (Approximate) : 1.34 lb (607.81 g)
- Kensington Security Slot : Yes
- Compatibility :
Apple Products:
- MacBook M1 Pro
- MacBook M1 Max
- MacBook M2 Max
- MacBook M2 Pro
- iPad
- MacBook M1
- MacBook M2
- Environmentally Friendly : Yes
- Country of Origin : Thailand
- Environmental Compliance : Restriction of Hazardous Substances (RoHS)
- Limited Warranty : 3 Year
SPECIFICATIONS
| Manufacturer | Kensington Computer Products Group |
| Manufacturer Part Number | K32856NA |
| Manufacturer Website Address | http://www.acco.com |
| Brand Name | Kensington |
| Product Model | SD5800T |
| Product Name | SD5800T Thunderbolt 4 and USB4 Quad Video Docking Station |
| Packaged Quantity | 1 |
| Package Type | Retail |
| Product Type | Docking Station |
| Connectivity Technology | Wired |
| Charging Capability | Yes |
| Device Supported | Monitor |
| Device Supported | Tablet PC |
| Device Supported | Notebook |
| Cable Length | 2.6 ft (0.80 m) |
| Memory Card Reader | Yes |
| Memory Card Supported | microSD |
| Memory Card Supported | SD |
| Features | Power Delivery Pass-through |
| Features | Plug & Play |
| Number of Displays Supported | 4 |
| Screen Mode Supported | 4K |
| Screen Mode Supported | QHD |
| Screen Mode Supported | 8K |
| Screen Mode Supported | 2K |
| Screen Mode Supported | 6K |
| Screen Mode Supported | Full HD |
| Supported Resolutions | 7680 x 4320 |
| Supported Resolutions | 1920 x 1080 |
| Supported Resolutions | 3840 x 2160 |
| Supported Resolutions | 2048 x 1080 |
| Supported Resolutions | 2560 x 1440 |
| Maximum Data Transfer Rate | 5 GB/s |
| Security Slot Type | Kensington Security Slot |
| Security Slot Type | Noble Wedge Security Slot |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Host Interface | Thunderbolt 4 |
| Total Number of USB Ports | 7 |
| Number of USB 2.0 Ports | 1 |
| Number of USB 3.2 Gen 1 Type-A Ports | 2 |
| Number of USB 3.2 Gen 2 Type-A Ports | 3 |
| Number of USB Type-A Ports | 6 |
| Number of USB Type-C Ports | 1 |
| USB Type-A | Yes |
| USB Type-C | Yes |
| USB Type-C Detail | 1 USB-C 3.2 Gen2 de 10 Gbps |
| Network (RJ-45) | Yes |
| Number of RJ-45 Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Number of DisplayPorts | 2 |
| DisplayPort | Yes |
| DisplayPort Version | 1.4 |
| Headphone/Microphone Combo Port | Yes |
| Number of HDMI Ports | 2 |
| HDMI | Yes |
| HDMI Version | 2.1 |
| Thunderbolt | Yes |
| Thunderbolt Ports Quantity | 1 |
| Number of Thunderbolt 4 Ports | 1 |
| USB Power Delivery | 100W |
| Operating System Supported | macOS Big Sur |
| Operating System Supported | Windows 10 |
| Input Voltage Detail | 230 V AC |
| Input Voltage Detail | 120 V AC |
| Maximum Power Supply Wattage | 170 W |
| Power Source Type | Power Supply |
| Color Family | Dual Color |
| Product Color | Black |
| Product Color | Cool Gray |
| Height | 7.68" (195 mm) |
| Width | 4.09" (104 mm) |
| Depth | 1.42" (36 mm) |
| Weight (Approximate) | 1.34 lb (607.81 g) |
| Package Contents |
|
| Kensington Security Slot | Yes |
| Compatibility | Apple Products:
|
| Brand Compatibility | Apple |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | Thailand |
| Limited Warranty | 3 Year |
